Platform Weighing Scale

Platform Weighing Scale - Accurately Manufactured With advanced Technology

A Platform Weighing Scale is a type of weighing device designed to measure the weight of objects placed on a platform or surface. These scales are commonly used in various industrial, commercial, and retail settings for accurately measuring the weight of goods, products, or materials.
As a client-focused organization, Swisser Instruments Pvt. Ltd. provides a diverse range of platform scales. These scales are in high demand for weighing many sorts of materials. Our expert workers use cutting-edge technology to create these scales from high-quality raw materials. We are one of the most reputable Platform Weighing Scale Suppliers in India. Our supplied scales are extensively verified by our quality analyzers against various quality criteria prior to final shipment.

Optional Attributes

Inbuilt Battery Back Up

Flame Proof Enclosure

Two Side Back Rail

Wire lessExtra Display

RS 232 ComputerInterface Port for Computer – Printer

2 To 20 mv Output / 0 to 5 V output

Look For the Top Brands of Platform Weighing Scale

The Platform Weighing Machine is built of stainless steel for long-lasting durability and effectiveness. It is suitable for industrial and commercial uses. The machine is equipped with a high-resolution load cell, overload stoppers, and transport protection. It is available in single and four-load cell configurations. The scale is made of high-quality steel and meets industrial requirements.
We are leading Platform Weighing Scale Manufacturers in India, providing high-quality machines with an appropriate and strong removable bracket for mounting the indication on the pole. It is lightweight, sturdy, and long-lasting equipment with a technologically advanced platform that may be used in a variety of application domains.

Specifications

Capacity: 50 kg to 5 Tn

Accuracy: 10 gm – 50 gm

Plate size: /Customized

Power use: 5 W

Internal resolution: 100000

Overload protection: 200%

Power supply : 190 V – 270 AC, 50 HZ

Operation temperature: 10oC to 50oC

Recharge battery: 6 V/ 4.5 Ah

Applications

Features

Inbuilt battery and auto charging feature

Durable mechanism with overload protection

Automatic voltage regulator

Technical Data

Designed On Advanced Micro Controller Technology

Power 230V AC + 10% 50 HZ

100,000 Internal Resolution

Sensor – High Quality Load Cell

Safe Overload Up to 200% of Rated Capacity

Temperature Range – 10° C to 50° C

Ultimate Overload Up to 300% of Rated Capacity

Optional – 6V / 4 AH Rechargeable Dry Battery

12.5 MM LED Display

PLAT FORM SERIES (Multifunction)

Model No Capacity  Accuracy  Pan Size
SWIP 202  20 Kg  2 gm 400 MM X 500 MM
SWIP 305  30 Kg  5 gm 400 MM X 500 MM
SWIP 505  50 Kg  5 gm 400 MM X 500 MM
SWIP 502  50 Kg  2 gm 400 MM X 500 MM
SWIP 605  60 Kg  5 gm 400 MM X 500 MM
SWIP 610  60 Kg  10 gm 400 MM X 500 MM
SWIPD 20/50  20/50 Kg  2/5 gm 400 MM X 500 MM
SWIPD 30/70  30/70 Kg  5/10 gm 400 MM X 500 MM
SWIPD 50/100  50/100 Kg 5/10 gm 400 MM X 500 MM
As Per Requirement
SWIP 100 100kg 10 gm  600 MM X 600 MM
SWIP200 200kg 20gm 600 MM X 600 MM
SWIP 300 300 kg 50 gm 600 MM X 600 MM
SWIP 500 500 kg 50 gm 600 MM X 600 MM
SWIP 100/200 100/200 kg 10/20 gm 600 MM X 600 MM
SWIP 200/500 200/500 kg 20/50 gm 600 MM X 600 MM
SWIP 100/300 100/300 kg 10/50 gm 600 MM X 600 MM
` As Per Requirement
